Before order,Please Read Clearly!
Which solar power system is suitable for me?
Sunheed solar systems can be used in homes, offices, villas, hospitals, churches, etc.
Sunheed solar power is from 300w to 100MW,
if you don’t know which model system is suitable for you,
Sunheed solar systems can be used in homes, offices, villas, hospitals, churches, etc.
Sunheed solar power is from 300w to 100MW,
you can choose according to your own needs.
if you don’t know which model system is suitable for you,
you can Send us an inquiry.
Our 10 years experience sale manager will help you configure the system in 12hrs.
Our 10 years experience sale manager will help you configure the system in 12hrs.
How to chose the suitable solar system?
★1.Chose solar system base on Installation area;
★2.Chose solar system base on your electricity bill;
★3.Chose solar system base on your home appliance capacity;
★4.Chose solar system base on your money/budget.
Send an inquiry, we can design a set of solar customized system that suits you best.
Product Description
New Off Grid Inverter 500VA 3000W 5000WATT Solar Power Inverter 12V to 230V Modify Sine Wave Solar Power Inverter Build Inside
MPPT 100A FOR Power System Home
Main Features
1. With MPPT solar charger controller built inside, Max PV input power reach to 5000W.
2. Wide PV input range (Up to 450Vdc), can work without battery during the day time.
3. Built-in wifi for mobile monitoring (requires App)
4. Optional for parallel operation up to 9 units for 5KW
5. Selectable charging current based on applications
6. Configurable AC/Solar input priority via LCD setting
7. Smart battery charger and management for optimized battery performance.Compitable with LI Ion, LiFePo4 and ect.
7. Smart battery charger and management for optimized battery performance.Compitable with LI Ion, LiFePo4 and ect.
8. 5KW Support Self-consumption and feed into the grid. Export excess pv power to grid via setting
9. Auto restart while AC is recovering, auto charge and switch, unattended operation
10. Various communication such as WIFI/RS485/RS232 optional.
11. High Efficient DC-To-AC Conversion.Minimizing Energy Loss and self power consumption
12. All around protection functions: Overload/short circuit protection/high voltage/low battery voltage/high temerature,etc.
13. 5KW Optional for self-consumption and feed into the grid by setting.
Specification
This is a hybrid inverter, Equipped with 80A AC charger and 5000watt MPPT solar charger, Its comprehensive LCD display offers
user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, work without
battery, Its also have opposite connection protection .
This is a hybrid inverter, Equipped with 80A AC charger and 5000watt MPPT solar charger, Its comprehensive LCD display offers
user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, work without
battery, Its also have opposite connection protection .
About the details and price ,feel free to contact with Customer service staff.Click Here.
|
Rated Power
|
SUNPOLO 3KW
|
SUNPOLO 5KW
|
||
|
INPUT
|
||||
|
Voltage
|
230VAC
|
|||
|
Voltage Range
|
176-280 VAC at 100% load
|
|||
|
110-280 VAC at 50% load
|
||||
|
Frequency Range
|
50Hz/60Hz(Auto sensing)
|
|||
|
OUTPUT
|
||||
|
AC Voltage Regulation(Batt.Mode)
|
230VAC±3%
|
|||
|
Surge Power
|
6400VA for 5 sec
|
10400VA for 5 sec
|
||
|
Efficiency(Peak)
|
>95% ( Rated R load, battery full charged
|
|||
|
Transfer Time
|
10ms typical (UPS)
|
|||
|
20ms typical (Appliances)
|
||||
|
Waveform
|
Pure sine wave
|
|||
|
BATTERY
|
||||
|
Battery Voltage
|
24 VDC
|
48 VDC
|
||
|
Floating Charge Voltage
|
27 VDC
|
54 VDC
|
||
|
Overcharge Protection
|
32 VDC
|
64 VDC
|
||
|
SOLAR CHARGER & AC CHARGER
|
||||
|
Solar Charger Type
|
MPPT
|
|||
|
Maximum PV Array Open Circuit Voltage
|
500VDC
|
|||
|
Maximum PV Array Power
|
4000W
|
5000W
|
||
|
MPP Range@ Operating Voltage
|
120-450VDC
|
120-450VDC
|
||
|
Maxmum Solar Charge Current
|
80A
|
80A
|
||
|
Maximum AC Charge Current
|
80A
|
|||
|
PHYSICAL
|
||||
|
Products Dimension,D X W X H (mm)
|
492*303*129
|
456*303*147
|
||
|
Product Net Weight(kgs)
|
10
|
12
|
||
|
Packing Dimension,D X W X H (mm)
|
570*395*215, 1PC/CTN
|
530*377*217,1PC/CTN
|
||
|
Product Net Weight(kgs)
|
11.5
|
13.5
|
||
|
Communication Interface
|
Removable OTG USB/RS232/RS458/BLE/Dry-contact,BMS interface,
|
|||
|
OPERATING ENVIRONMENT
|
||||
|
Humidity
|
5% to 95% Relative Humidity(Non-condensing)
|
|||
|
Operating Temperature
|
-10℃ to 50℃
|
|||
|
Storage Temperature
|
-15℃ to 60℃
|
|||
|
*Product specifications are subject to change without further notice
|
||||
Production & QC
1.3IN1
MPPT INVERTER, ON GRID/OFF GRID/HYBRID.
Communication optional: USB/RS232/RS485/Dry-Contact/WIFI
2.Dual MPPT
Dual MPPT tracker inside (2pcs*18A), max PV input 8000W
Real hybrid can feed-in to grid Works with & without battery
Parallel up to 6pcs optional
Smart battery management, reserved communication port for BMS
3. RGB light
Touchable LCD screen
RGB light
WIFI monitor optional
4. International Certification Examining
Authoritative certification companies conduct rigorous testing to ensure that product quality meets first-class international
certification.
certification.
