Model
|
BMMX07T2-04
|
BMMX11T2-05
|
BMMX22T2-06
|
|||
|
Technical Features
|
||||||
|
Category
|
IEC62196 Type 2
|
|||||
|
Output Power
|
7kw
|
11kw
|
22kw
|
|||
|
Input max current
|
32A 1phase
|
16A 3phases
|
32A 3phases
|
|||
|
Rated Voltage
|
230VAC±10%
|
380VAC±10%
|
380VAC±10%
|
|||
|
Rated Frequency
|
50/60HZ
|
|||||
|
RCD
|
Type A+DC 6Ma
|
|||||
|
Load Balancing
|
DLB /Meter(Optional)
|
|||||
|
Connector Type
|
IEC62196-2 Type 2 5meters/customize TPU (TUV CE ROHS UKCA CB Certificate)
|
|||||
|
Connector Mechanical Operating Life
|
>10000 times
|
|||||
|
Charging Control
|
RFID/APP/OCPP Optional
|
|||||
|
Display Screen
|
LCD 4.3inch/LED
|
|||||
|
Cummunication Protocol
|
OCPP1.6 (Optional)
|
|||||
