Product Shows
|
Technical Parameters
|
||||||||||||
|
Model
|
JW1230
|
JW1240
|
JW1250
|
JW2450
|
JW2460
|
|||||||
|
Rated voltage
|
12v/24v auto
|
12v/24v auto
|
12v/24v auto
|
24V
|
24V
|
|||||||
|
Solar panel power
|
100W
|
100W
|
100W
|
300W
|
400W
|
|||||||
|
Wind turbine power
|
300W
|
400W
|
500W
|
500W
|
600W
|
|||||||
|
Charging
|
Charging current
|
33.33A
|
41.66A
|
50A
|
33.33A
|
41.66A
|
||||||
|
Equalization charge
|
14.4V±1%
|
28.8V±1%
|
||||||||||
|
Floating Charge
|
13.8V±1%
|
27.6V±1%
|
||||||||||
|
Equalization charge recovery
|
13.2V±1%
|
26.4V±1%
|
||||||||||
|
Temperature Compensation
|
-24mV/℃
|
-48mV/℃
|
||||||||||
|
Over Discharge
|
Disconnect (DC)
|
10.8V±1%
|
21.8V±1%
|
|||||||||
|
Recovery (DC)
|
12.3V±1%
|
24.6V±1%
|
||||||||||
|
Over Voltage
|
Shut off (DC)
|
16V±1%
|
32V±1%
|
|||||||||
|
Recovery (DC)
|
15V±1%
|
30V±1%
|
||||||||||
|
No-load
|
≤0.1A
|
≤0.1A
|
||||||||||
|
Voltage drop (DC)
|
≤0.5V
|
|||||||||||
|
Control mode
|
Wind generator MPPT charge function, PWM uninstall function, PWM over-current limiting
|
|||||||||||
|
Boost charge
|
Flexible independent step-up circuit (optional)
|
|||||||||||
|
Display
|
LCD
|
|||||||||||
|
Show parameters
|
Voltage、charge current，battery voltage
|
|||||||||||
|
Protected type
|
Lightning protection, solar cell anti-reverse protection, open battery protection, reverse battery protection, over-wind speed and
over-voltage soft automatic braking protection |
|||||||||||
|
Heat emanation way
|
Radiator
|
|||||||||||
|
Working Temperature
|
-25℃~+55℃
|
|||||||||||
|
Height
|
≤5500m(2000m above the need to reduce power use)
|
|||||||||||
|
Environment humidity
|
0~90%，No condensation
|
|||||||||||
