Specification
|
Technical parameters:
|
||||||||
|
Type(unit)
|
SuninvM MPPT 3K 24V
|
SuninvM MPPT 3K 48V
|
SuninvM MPPT 4K 48V
|
SuninvM MPPT 6K 48V
|
||||
|
Rated capacity
|
3KVA
|
3KVA
|
4KVA
|
6KVA
|
||||
|
Battery rated voltage
|
24V
|
48V
|
48V
|
48V
|
||||
|
PV maximum input open voltage
|
225V
|
225V
|
225V
|
225V
|
||||
|
MPPT voltage range
|
150V
|
150V
|
150V
|
150V
|
||||
|
Voltage range
|
110/220VAC ±15%
|
|||||||
|
Frequency
|
50/60Hz
|
|||||||
|
Rated charge current
|
30A
|
30A
|
30A
|
30A
|
||||
|
Rated output voltage
|
110/220V ±15%
|
|||||||
|
Rated output frequency
|
50/60Hz ±1%
|
|||||||
|
Rated output current
|
13.6A
|
13.6A
|
18.2A
|
27.3A
|
||||
|
Output power factor
|
≥0.8
|
|||||||
|
THD
|
<3%
|
|||||||
|
Output wave
|
Sine wave
|
|||||||
|
Output phase
|
Single phase
|
|||||||
|
Peak factor
|
3:1
|
|||||||
|
PV charge current
|
2*60A
|
2*30A
|
2*40A
|
2*60A
|
||||
|
Efficiency
|
≥90%
|
|||||||
|
Dynamic response
|
5% (load from 0 to 100%)
|
|||||||
|
Noise level
|
≤40dB (1m distance)
|
|||||||
|
Display interface
|
LCD
|
|||||||
|
Communication interface
|
USB
|
|||||||
|
Environmental temperature
|
-30+55℃
|
|||||||
|
Environmental humidity
|
10%-90% （non condensing）
|
|||||||
|
Protection level
|
IP21
|
|||||||
|
Protection function
|
Array/ Over voltage/ Over current/ Short circuit/ Reverse connection ect protection function
|
|||||||
|
Altitude (m)
|
≤2000 ( above 1000m need according GB/T3859.2 to derate operating)
|
|||||||
|
Dimensions (mm)
|
420*640*210(W*H*D)
|
|||||||
|
Weight (kg)
|
20
|
25
|
25
|
30
|
||||
|
Warranty
|
2 years
|
|||||||
|
Certificate
|
CE/ ISO9001
|
|||||||
