| Model | 3000VA/3000W | 5000VA/5000W | |
| Input | Input Sources | L + N + PE | |
| Rated Input Voltage | 208 / 220 / 230 / 240VAC | ||
| Voltage Range | 170-280VAC (Computers);90-280VAC (Appliance) | ||
| Freqency | 50HZ / 60HZ ( Auto Adaptive ) | ||
| Output | Rated Capacity | 3000W | 5000W |
| Output Voltage | 208 / 220 / 230 / 240VAC ± 5 % | ||
| Output Frequency | 50 / 60HZ ± 0.1 % | ||
| Waveform | Pure Sine Wave | ||
| Transfer Time( adjustable ) | Computers ( UPS Mode ) 10ms , Appliance ( APP Mode ) 20ms | ||
| Peak Power | 6000VA | 10000VA | |
| Over Load Ability | Battery Mode 1min @ 102 % -110 % Load 10s @ 110 % -130 % Load 3s @ 130 % -150 % Load 200ms @ > 150 % Load |
||
| Peak Efficiency(battery Mode) | > 94% | > 94% | |
| Battery | Battery Votage | 24vdc | 48vdc |
| Constant Charging Voltage(Adjustable) | 28. 2vdc | 56.4vdc | |
| Floate ChargingVoltage(Adjustable) | 27vdc | 54vdc | |
| Chargers | PV Charging Mode | MPPT | MPPT |
| MAX.PV Input Power | 1500W | 5500W | |
| MPPT Tracking range | 30-115vdc | 120-430vdc | |
| MAX.PV Input Voltage | 145vdc | 450vdc | |
| MAX.PV Charging Current | 60A | 60A | |
| MAX.AC Charging Current | 60A | 60A | |
| MAX.Charging Current | 120A | 60A | |
| Display | LCD Display | Display Running Mode / Loads / Input / Output etc | |
| Interface | RS232 | 5PIN/Pitch2.0mm, Baud rate 2400 | |
| Communication Port | 2X5PIN / Pitch2.54mm , Lithium Lattery BMS Communication Card,Wificard ,Dry Contact | ||
| Physical | Size(mm) | 102*305*465 | |
| Package weight(kg) | 8.5 | 10 | |
| Environments | Operating Temperature | 0 ~ 40℃ | |
| Humidity | 20 % ~ 95 % ( non-condensing ) | ||
| Storage Temperature | -15~60℃ | ||
| Altitude | Altiude Not Over 1000m , Derating over 1000m , Max 4000m , Refer to IEC62040 | ||
| Noise | ≤ 50db | ||
