Product Description
Data Sheet
|
Model No.
|
JSK-H4850E80P
|
|
|
Basical Information
|
||
|
Max. PV Input Power
|
5000W
|
|
|
Rated AC Output Power
|
5000W
|
|
|
Grid-Tie Operation
|
||
|
PV Input (DC)
|
||
|
Nominal DC Volt/Max DC Voltage
|
360VDC/500VDC
|
|
|
Start-up Voltage/Initial Feeding Voltage
|
120VDC
|
|
|
MPPT Voltage Range
|
120-450VDC
|
|
|
No. of MPPT Tracker/Max. Input Current
|
1/27A
|
|
|
AC Input (AC)
|
||
|
AC Start-up Voltage/Auto Restart Volt.
|
120Vac-140Vac/180Vac
|
|
|
Acceptable Input Voltage Range
|
90-280Vac or 170-280Vac
|
|
|
Max. AC Input Current
|
40A
|
|
|
Grid Output in Grid-Tie/Hybrid Operation (AC)
|
||
|
Nominal Output Volt
|
220Vac/230Vac/240Vac, Single Phase
|
|
|
Output Voltage Range
|
184V-265Vac or 195-253V (Selectable)
|
|
|
Nominal Output Current
|
26.0A
|
|
|
Power Factor
|
1
|
|
|
Max. Conversion Efficiency (DC/AC)
|
96%
|
|
|
Battery Mode Output (AC)
|
||
|
Nominal Output Volt
|
220Vac dual AC output+1pc*12Vdc/10A max
|
|
|
Waveform
|
Pure sine wave
|
|
|
Efficiency(DC to AC)
|
>95%
|
|
|
Battery & Charger
|
||
|
Battery Type Supported
|
Lead Acid/VRLA/AGM/Gel/Flooded/Tubular/Lithium-Ion
|
|
|
Nominal Battery Voltage
|
48Vdc
|
|
|
Max Solar Charge Current
|
120A
|
|
|
Max AC Charge Current
|
120A
|
|
|
Max Total Charge Current
|
120A
|
|
|
General
|
||
|
Physical
|
||
|
Products Dimension,D X W X H (mm)
|
456*303*147mm
|
|
|
Product Net Weight(kgs)
|
12
|
|
|
Product Gross Weight(kgs)
|
13.5
|
|
|
Packing Dimension,D X W X H (mm)
|
530*377*217MM,1PC/CTN
|
|
|
Parallel functions Optional
|
Yes, optional, MAX. 9pcs
|
|
|
Communication Interface
|
RS232,USB,WIFI,TOUCH LCD
|
|
|
Environment
|
||
|
Humidity
|
5% to 95% Relative Humidity(Non-condensing)
|
|
|
Operating Temperature
|
-10℃ to 50℃
|
|
|
Storage Temperature
|
-15℃ to 60℃
|
|
