ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
WHY CHOOSE US?
Free sample Client tell you.
Advantage
why choose us
The quality and service let you know
1.APPLICATION
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
4.Construction
| Datasheet | SPF 3500 ES | SPF 5000 ES |
| Battery Voltage | 48VDC | |
| Battery Type | Lithium/Lead-acid | |
| INVERTER OUTPUT | ||
| Rated Power | 3500VA/ 3500W | 5000VA/ 5000W |
| Parallel Capability | Yes, 6 units maximum | |
| AC Voltage Regulation (Battery Mode) | 230VAC ± 5% @ 50/60Hz | |
| Surge Power | 7000VA | 10000VA |
| Efficiency (Peak) | 93% | |
| Waveform | Pure sine wave | |
| Transfer Time | 10ms typical, 20ms Max | |
| SOLAR CHARGER | ||
| Maximum PV Array Power | 4500W | 6000W |
| MPPT Range @ Operating Voltage | 120VDC ~ 430VDC | |
| Number of Independent MPP Trackers/ Strings Per MPP Tracker | 1/1 | |
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum Solar Charge Current | 80A | 100A |
| AC CHARGER | ||
| Charge Current | 60A | 80A |
| AC Input Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | |
| Frequency Range | 50Hz/60Hz (Auto sensing) | |
| PHYSICAL | ||
| Protection Degree IP20 | ||
| Dimension (W/H/D) | 330/485/135mm | 330/485/135mm |
| Net Weight | 11.5kgs | 12kgs |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Altitude | <2000m | |
| Operating Temperature | 0°C – 55°C | |
| Storage Temperature | -15°C – 60°C | |
5.Our work shop
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
6.QC
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
7.Certificate
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
8.Packing
1 pc/2 pcs/4 pcs each carton with wooden pallet or as your request
The packing
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
9.About ESG
The cllient feed back
Free Sample Toys tools Green Energy AGM Sealed Lead Acid Batteries12V7ah12ah Back UPS battery
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
10.Main fair
ESG Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
Please contact us for more details and send us your inquiry!!!!
