Product Description
Specification
|
Model
|
FT-202
|
FT-302
|
FT-402
|
FT-502
|
FT-602
|
|||||
|
Rated power
|
2KW
|
3KW
|
4KW
|
5KW
|
6KW
|
|||||
|
Surge power
|
6KW
|
9KW
|
12KW
|
15KW
|
18KW
|
|||||
|
AC Input & Output
|
||||||||||
|
Voltage
|
220VAC
|
|||||||||
|
Selectable Voltage Range
|
165-275VAC (220VAC)
|
|||||||||
|
Frequency Range
|
50Hz/60Hz automatic recognition
|
|||||||||
|
AC Voltage Regulation
(BATT. Mode)
|
(DC Batt.mode)220vac±3%
|
|||||||||
|
Transfer Time
|
≤4ms
|
|||||||||
|
Wave Form
|
Pure Sine Wave
|
|||||||||
|
Transformer type
|
Toroidal
|
|||||||||
|
Transfer efficiency
|
≥85%
|
|||||||||
|
Battery
|
||||||||||
|
Battery Voltage
|
12V/24V/48V
|
24V/48V
|
||||||||
|
Type
|
Gel/SLA/AGM/Water/Lithium(lifepo4) Battery
|
|||||||||
|
DC Charge Voltage
|
12~16VDC(12V)/20~32VDC(24V)/40~64VDC(48V)
|
|||||||||
|
Overcharge Protection
|
Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm
|
|||||||||
|
AC Charger
|
||||||||||
|
Maximum Ac Charge Current
|
35A (adjustable)
|
|||||||||
|
Working mode
|
||||||||||
|
01 mode
|
AC mains priority mode
|
|||||||||
|
02 mode
|
ECO mode
|
|||||||||
|
03 mode
|
DC battery priority mode
|
|||||||||
|
04 mode
|
Generator mode
|
|||||||||
|
05 mode
|
Unattended mode
|
|||||||||
|
Communication Port
|
||||||||||
|
Type
|
RS485, available for wifi box & external control screen
|
|||||||||
|
Physical
|
||||||||||
|
Dimension,
D*W*H(MM)
|
600*380*170
|
780*380*280
|
||||||||
|
G.W.(KGS)
|
19
|
21
|
31
|
33
|
35
|
|||||
|
Environment
|
||||||||||
|
Humidity
|
0~95%（NO CONDESNSATION)
|
|||||||||
|
Operating Temperature
|
0~60℃
|
|||||||||
|
Storage Temperature
|
0~60℃
|
|||||||||
|
*Product Specifications Are Subject To Change Without Further Notice
|
||||||||||
