Configuration Details
⭐Solar Panels
✅Peak Power: 550W.
✅Peak Voltage: 40.90V.
✅Peak Current: 13.45A.
✅±Tolerance: -0~+3%. ✅Materials:Monocrystalline Silicon.
✅Batteries Number: 144.
✅Warranty: 15 Years.
✅Warranty: 15 Years.
⭐Solar Inverter
✅Rated Power: 5.5/6.2kW.
✅Input Voltage: 220/230/240V.
✅Output Voltage: 208/220/230/240V.
✅Output Type: 1/3 Phase.
✅System Type: Hybrid/Off Grid.
✅Warranty: 5 Years.
✅Output Voltage: 208/220/230/240V.
✅Output Type: 1/3 Phase.
✅System Type: Hybrid/Off Grid.
✅Warranty: 5 Years.
⭐
Solar Battery
Solar Battery
✅Certification: CE, FCC, MSDS, UN38.3. ✅Battery Materials: Level A LiFePO4. ✅Capacity: 100/200/300Ah.
✅Rated Voltage: 51.2V.
✅Cycle Life: 8000 Cycles.
✅OEM/ODM: Yes.
✅Warranty: 10 Years.
✅OEM/ODM: Yes.
✅Warranty: 10 Years.
⭐Installation System
✅Installation Mode: Roof Mounting/ Ground Mounting/ Carport Mounting.
✅Support Material: Aluminium Alloy. ✅Tools Bag: Selectable.
✅MC4 Connector: 30A, 1000VDC.
✅MC4 Connector: 30A, 1000VDC.
✅PV Combiner Box: 8 Inputs, 1 Outputs. ✅PV Cable: 4mm².
✅Breakers Switches: Selectable.
⭐Accessories
✅PV Combiner Box: 1000/1500V DC optional,PV high voltage arester protection,
Circuit breaker protection, Lightning protection
✅PV Cable: 4mm²/6mm²/10mm² optional
✅MC4 Connection: Compatible, 30A/1000V DC
✅Solar System Installation Tools
Solar System Customization
Solar Panels
Product quantity, power, packaging
can be customized.
Solar Inverter
95% of the brand inverters on the market are optional.
Solar Battery
Capacity, voltage, frame, shell, pattern can be customized.
Collecting Box
Thunderstorm and surge protection, wide input voltage.
Installation System
Roof Mounting/Ground Mounting/Carport Mounting.
PV Cable
4mm², 6mm², 10mm² optional.
Rated voltage 600~1000VDC.
Rated voltage 600~1000VDC.
Product Description
|
Components
|
3KW-OFF
|
5KW-OFF
|
8KW-OFF
|
10KW-OFF
|
20KW-OFF
|
||||
|
580W Solar Panel
|
5 Pieces
|
8 Pieces
|
14 Pieces
|
16 Pieces
|
36 Pieces
|
||||
|
Combiner Box
|
5 in 1 out
|
4 in 1 out
|
7 in 1 out
|
8 in 1 out
|
9 in 1 out
|
||||
|
Off Grid Inverter
|
3kw
|
5kw
|
8kw
|
10kw
|
20kw
|
||||
|
12V 200AH/250 GEL Battery
|
2 Pieces
|
4 Pieces
|
4 Pieces
|
8 Pieces
|
2 Pieces
|
||||
|
DC Cable
|
100 Meters
|
200 Meters
|
200 Meters
|
200 Meters
|
100 Meters
|
||||
|
MC4 Connector
|
4 Pairs
|
6 Pairs
|
6 Pairs
|
8 Pairs
|
10 Pairs
|
||||
|
Mounting System
|
Ground or Roof （Customized Optional）
|
||||||||
Application
30KW Off-Grid Solar Power Supply System In Chile
50KW Grid-Tied Solar Power System For Agriculture In Turkey
6KW Roof off grid solar power system with battery case, Spain
